DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available)

DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) SALE
DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available) DE23 Gen4 Teir 4 Final Open Skid Prime Power (47 Gal. tank option available)

Winco

$ 23,000.00
SKU: DE23-1

← Previous Product Next Product →

PRODUCT DESCRIPTION

Our DE23 has great features, such as a standard rocker manual controller, the new Isuzu 4LE2T series engine, service access on one side, Electronic Common Rail, and radiator ducting, to name a few.

  • Product Features

    Isuzu 4LE2T 2.2 Liter Engine
         Dependable 4 cylinder, 1800 RPM engine.
         EPA compliant, tier 4 final.
    Rocker Manual Start
         Standard manual start control panel is easy to use with
         an hour meter, voltmeter, and safety features.
    Stamford Generator End
         Alternators built to produce clean power for industrial
         applications.
    Powder Coat Paint
         Provides a durable, long lasting finish.
    UL2200 Listed
         A safety standard for the design, construction, and
         performance of stationary generators.
    100% Load Tested
         We load test every generator before it leaves our factory.

Additional Information

Standby Watts

120/240 1-PH: 20,000
120/208 3-PH: 23,000
120/240 3-PH: 23,000
277/480 3-PH: 23,000
Prime Watts

120/240 1-PH: 19,800
120/208 3-PH: 20,700
120/240 3-PH: 20,700
277/480 3-PH: 20,700
Standby Amps

120/240 1-PH: 91
120/208 3-PH: 79
120/240 3-PH: 69
277/480 3-PH: 34
Prime Amps

120/240 1-PH: 82
120/208 1-PH: 71
120/240 3-PH: 62
277/480 3-PH: 31
Voltage Output

120/208 Volt Three Phase, 120/240 Volt Single Phase, 120/240 Volt Three Phase, 277/480 Volt Three Phase
Voltage Regulation

AVR – AS440 +/- 1%
Engine

Brand: Isuzu
Model: 4LE2T
Fuel

Diesel
Emissions

Tier IV Final
Dimensions

66.7" x 33.6" x 43.4"
Weight

Without Tank: 1,450 lbs
With Tank: 1,650 lbs
Unit Warranty

1 year/2000 hours
Assembled In

USA



Additional Required Option:

Controller - DSE7310 / Rocker Manual Start

Additional Optional Equipment:

Start Battery        2.0 Amp Battery Charger        Engine Coolant Heater

Remote E-Stop          Maintenance Kit



Spec Sheet               7310 MKII Spec Sheet

     Manual                          Manual
