DR1214 Liquid Cooled Diesel Standby (Open Skid / Housed / Aluminum Housing / Towable)
Product Description
Our DR12I4 has been redesigned with an Isuzu 3CE1 engine for standby and prime applications. This unit has been engineered with an Isuzu engine coupled to a Stamford generator end. We believe this unit is the best on the market.
-
Isuzu 3CE1 1.6 Liter EngineThis Isuzu engine is a dependable tier 4 Final, 3 cylinder, 1800 RPM engine.DSE7310The DSE7310 MKII is a powerful, new generation auto startgenset control module with a highly sophisticated level of newfeatures and functions, presented in the usual DSE user-friendly format.Stamford Generator End
Industrial grade generator ends predominantly used for
standby applications. These alternators are very versatile for more demanding and challenging applications.Battery ChargerFactory installed 3 stage, 5 Amp battery charger.Block HeaterIn-line, 120V, block heater with thermostat.Powder Coat PaintProvides a durable, long lasting finish.UL2200 ListedA safety standard for the design, construction, andperformance of stationary generators.100% Load TestedWe load test every generator before it leaves our factory
Additional Information
| Watts |
Standby: 12,500 |
|---|---|
| Amps - Standby |
120/240 1-Ph: 52 |
| Amps - Prime |
120/240 1-Ph: 46 |
| Voltage Regulation |
AVR (Automatic Voltage Regulator) |
| Voltage Output |
120/208 Volt Three Phase, 120/240 Volt Single Phase, 120/240 Volt Three Phase, 277/480 Volt Three Phase |
| Engine Brand |
Isuzu |
| Fuel |
Diesel |
| Emissions |
EPA Prime, EPA Standby |
| Dimensions |
Open Skid: 63" x 34" x 33.71" |
| Weight |
1790 lbs. |
| Unit Warranty |
Standby: 2 yr/2000 hrs |
| Assembled In |
USA |
Fuel Tank Options:
Spec Sheet Parts List Outline Drawing DSE7310
Operator/Install Manual Open Skid Install Manual
